USB modular socket

USB modular Socket

         The USB modular Socket , which is suitable for using in the load circuit of voltage input 90V~250V, AC50/60Hz and output DC 5V/2.1A.  Electrical  Power Consumption Socket is reliable, suited with din rail installation and can be matched with other terminal electric modular products. It 's use in many ways.

Specifications

USB modular Socket

input

Nominal Voltage: AC90~240V 50/60HZ

Nominal current: 0.18A (Max)

output

Nominal Voltage: DC 5V

Nominal current: 2.1A (Max)

Out Characteristics

Application:

USB Modular Socket can be used together with our other modular products for connection of mobile devices ,tools or electric and electronic non-modular equipments directly inside civil , industrial switchboards, Monitoring equipment and communication equipment
